SMD3535 P10 IP65 Outdoor Full Color Led Display Advertising Screen
SMD3535 P10 Led Display High Brightness Advertising Screen Big Size sports perimeter led display
Quick details of sports perimeter led display
1) Die casting aluminum cabinet with size of 960*960mm.
2) Omnidirectional waterproof, prefect work in rainy days.
3) Easy maintenance and fast installation.
4) Adopt anti collision design to protect athletes and screens better.
Specifications of sports perimeter led display
| Item | P6.67 | P8 | P10 |
| Pixel pitch | 6.67mm | 8mm | 10mm |
| Module size | 320*160mm | 320*160mm | 320*160mm |
| Module resolution | 48×24 | 40×20 | 32×16 |
| Physical density | 22477 dots/㎡ | 15625 dots/㎡ | 10000 dots/㎡ |
| LED type | SMD3535 | SMD3535 | SMD3535 |
| Cabinet size | 960mm×960mm | 960mm×960mm | 960mm×960mm |
| Cabinet resolution | 144×144 | 120×120 | 96×96 |
| Cabinet material | Die casting aluminum | Die casting aluminum | Die casting aluminum |
| Maintenance way | Rear | Rear | Rear |
| Best viewing distance | ≥6.6m | ≥8m | ≥10m |
| Best viewing angle | H: 140°; V:140° | H: 140°; V:140° | H: 140°; V:140° |
| Driving method (Constant Current) | 1/6 Scan | 1/5 Scan | 1/2 Scan, |
| Video frame rate | ≥60 Hz | ≥60 Hz | ≥60 Hz |
| Refresh rate | 1920-3840Hz | 1920-3840Hz | 1920-3840Hz |
| Brightness | ≥5500nits | ≥5500nits | ≥6000nits |
| Grey Level | 12-16bit | 12-16bit | 12-16bit |
| Ingress protection | IP65 | IP65 | IP65 |
| Life Time | >100,000 Hours | >100,000 Hours | >100,000 Hours |
| The rate | <0.0002 | <0.0002 | <0.0002 |
Features of sports perimeter led display
1. Adopt anti collision design. protect athletes and screens better.
2. Easy maintenance and quickly disassembly
3. 100% waterproof. even can work on extreme weather
4. Large viewing angle.can be seen clear with different angles
Why choose KAILITE?
1. We are a 14 years leading manufacturer specialized in led display industry.
2. High quality.We will conduct product inspection every working processes.
3. Quickly response.we will response with 24 hours
4. Cost-effective price.We are the original manufacturer, no middleman make the difference.
After-sell Service:
1) 2 yaers quality guarantee period for all parts.
2) We will provide free frame structure drawing, as well as power and data cables wiring diagram. easy for your to set up the led screen .
3) We can provide you long-distance control if you need.
4) keep in touch to solve any problems.
5) Remote guidance installation and maintenance.
FAQ:
1. I want to have an sample, can you provide?
Sure, free feel to contact us!
2. What is the warranty of your led display?
2 years warranty.
3. Are you a trade company or a factory?
We are a factory. We can provide you factory price.
4. How long will it take to receive the goods?
About 22-24 days.
5. Do you support print logo?
Yes.we can provide this service to you for free.
